| Specification | H-250 10" CH | H-300 12" CH | H-375 15" CH |
| CAPACITY | |||
| Center Height |
204mm (8") | 204mm (8") | 204mm (8") |
| Admit Between Center |
533mm (21") | 650mm (25") | 965mm (38") |
| Swing over bed |
406mm(16") | 406mm(16") | 406mm(16") |
| Swing over Cross Slide |
270mm (10") | 270mm (10") | 270mm (10") |
| Swing in Gap |
610mm (24") | 610mm (24") | 610mm (24") |
| Width of Gap |
125mm | 125mm | 125mm |
| Width of Bed |
270mm (10") |
270mm (10") | 270mm (10") |
| Bed Type |
2V-2Flat | 2V-2Flat | 2V-2Flat |
| Bed Length | 1375mm (4'6") | 1600mm (5'3") | 1825mm (6') |
| HEADSTOCK | |||
| Spindle Nose / Dia. |
THREADED / Dia. 74.3mm |
THREADED / Dia. 74.3mm | THREADED / Dia. 74.3mm |
| Spindle Bore / Taper |
50mm / MT - 4 |
50mm / MT - 4 | 50mm / MT - 4 |
| Spindle Speed / Range | 6 / 40-950rpm |
6 / 40-950rpm | 6 / 40-950rpm |
| V-Belt | B-48 | B-48 | B-48 |
| SLIDE | |||
| Cross Slide Movement |
205mm |
205mm | 205mm |
| Toolpost Slide Movement | 120mm | 120mm | 120mm |
| NORTON GEAR BOX | OPTIONAL | OPTIONAL | OPTIONAL |
| Metric Threads |
1-6mm |
1-6mm | 1-6mm |
| Inch Threads |
2-24 TPI |
2-24 TPI | 2-24 TPI |
| Lead Screw Dia. x TPI | Dia. 1" x 4TPI | Dia. 1" x 4TPI | Dia. 1" x 4TPI |
| TAILSTOCK | |||
| Ram Dia. |
50mm |
50mm | 50mm |
| Ram Travel |
150mm |
150mm | 150mm |
| Taper in Ram | MT-3 | MT-3 | MT-3 |
| POWER SUPPLY |
3Ph, 415v, 50Hz |
3Ph, 415v, 50Hz | 3Ph, 415v, 50Hz |
| Motor Power |
2HP / 1.5 Kw | 2HP / 1.5 Kw | 2HP / 1.5 Kw |
| FLOOR SPACE OCCUPIED Approx L x W x H |
1675 x 540 x 1160mm | 1800 x 540 x 1160mm | 2125 x 540 x 1160mm |
| Net Weight Approx | 650 Kgs.. | 750 Kgs. | 825 Kgs. |
Standard Accessories
| Chuck Plate | Dead Center - 2 Nos | Toolpost Key | Change Gears for Inch / MM Threads |
| Center Adaptor | 4-Position Square Toolpost | Thread Dial Indicator | Motor Pulley |
Optional Accessories :
| Electric Motor with Rev/For Switch & Wiring |
Chuck Plate | 10" x 4 Jaw Independent Chuck | Steady Rest, Follow Rest, |
| Face Plate | 8" x 3 Jaw True Chuck | Taper Turning Attachment, Steady Rest | Norton Gear Box |
